    2.8 MPa LNG bullet storage tanks

    Ask Lasest Price
    Brand Name : MKIMM
    Model Number : MKIMM
    Certification : ISO
    Price : bargain
    Payment Terms : T/T,L/C,Paypal,Alipay,West Union and so on
    Supply Ability : 25 every month
    Delivery Time : 15days
    • Product Details
    • Company Profile

    2.8 MPa LNG bullet storage tanks

    30m3 Long Service Life Cryogenic Liquid Carbon Dioxide Storage Tank


    Description

    Cryogenic LCO2 tanks are available in vertical or horizontal structures for customers to choose from, and are suitable for storage and transportation of liquid oxygen, liquid nitrogen, argon, natural gas to carbon dioxide. Models range from 3 m3 to 200 m3 (525 to 52,800 gallons) and pressures up to 25 barg. We offer a wide range of cryogenic storage tanks from standard to specialty and custom designs.


    Advantage

    Our double-layer insulated vacuum insulated cryogenic storage tanks have national performance type test reports and the daily evaporation rate is below the standard. The vacuum degree is as high as 0.05pa, and the vacuum is guaranteed to be maintenance-free for 3 years. Compared with the perlite vacuum insulation tank, the advantages are better insulation, lighter weight, and the insulation layer will

    Does not sink after vibration or prolonged use.


    Parameter

    Model(CFL/W)5101520305060100150200250
    Inner tank/outer tank materialS30408/Q345R(CO2inner tank:16MnR)
    Operation pressure0.2/0.8/1.2/1.6/2.8 MPa
    Volume (m3)5101520305060100150200250
    Inner tank size (m)1.41.81.822.22.52.733.33.53.6
    Outer tank size (m)1.92.32.32.52.733.23.53.844.1
    Daily evaporation rate(%/d)o20.40.360.350.330.290.230.210.160.140.130.12

    main products

    The company mainly produces large-scale low-temperature storage tanks, underground double-layer oil tanks, LPG storage tanks, skid-mounted and other special-grade pressure vessels. The company has professional research and production personnel, and the service life of large-scale pressure vessels produced through the production line can be extended to about 20 years.

    co2 tank

    co2 tank
