Natural Gas Shell And Tube Heat Exchanger Hot Sale

Description

Shell and tube heat exchangers still dominate the heat exchange equipment used in chemical production. Although it is not as good as other new heat exchange equipment in terms of heat exchange efficiency, compact structure and metal material consumption, the shell and tube heat exchanger has the advantages of solid structure, large operation flexibility, strong adaptability, high reliability and a wide range of materials. , large processing capacity, can withstand high temperature and high pressure and other characteristics, so it is still widely used in engineering.

Specification

product structure

Shell-and-tube heat exchangers consist of shells, heat transfer tube bundles, tube sheets, baffles (baffles) and tube boxes. The shell is mostly cylindrical, with tube bundles installed inside, and both ends of the tube bundles are fixed on the tube sheet. Two fluids, hot and cold, for heat exchange, one flows inside the tube, called the tube side fluid; the other flows outside the tube, called the shell side fluid. In order to improve the heat transfer coefficient of the fluid outside the tube, several baffles are usually installed in the shell. The baffle can increase the velocity of the fluid on the shell side, forcing the fluid to pass through the tube bundle several times laterally according to the prescribed path, and enhance the degree of fluid turbulence. The heat exchange tubes can be arranged in equilateral triangles or squares on the tube sheet. The equilateral triangle arrangement is compact, the fluid outside the tube has a high degree of turbulence, and the heat transfer coefficient is large; the square arrangement is convenient for cleaning outside the tube, and is suitable for fluids that are prone to scaling.

As a professional pressure vessel enterprise, Henan Mikim Machinery Co., Ltd. has been involved in the pressure vessel industry since 2012. Our company can provide products such as large cryogenic storage tanks and LPG series containers. At the beginning of the company's establishment, it purchased the most advanced equipment and recruited a group of skilled front-line workers. We are committed to providing the best products to our international customers. The company covers an area of 68,000 square meters and has 100 front-line workers, 12 technicians and 6 quality inspectors. The integration of production and sales, the company consists of five main departments: production department, technical department, sales department, general accounting department, and human resources department. Also, each department can be divided into many smaller departments. All departments cooperate with each other to bring the best for our company. In order to bring the most qualified products to the market, our quality control department implements strict quality inspection process from raw material procurement to finished product testing, to ensure that only the best products leave the factory for customers.

The group adheres to the tenet of “intentional management, customer priority, coordinated development and dedication to society” and abides by the business philosophy of “technology first, quality as priority, striving for excellence, integrity for future”, which continuously satisfy different needs of customer around the world in the steel supply chain area. Professional sales team, providing customers with first-class services; strict purchasing and quality inspection team, carefully selecting high-quality raw materials; advanced scientific and technical team to improve production and reduce costs for customers; excellent design and processing team, carefully crafted and refined; intimate shipping logistics team protecting product transportation.
